Resistance Electric Boiler

In Stock

The Resistance Electric Steam Boiler by YXBOILER converts electrical energy directly into steam through high-grade stainless steel immersion heating elements, achieving near 100% thermal efficiency with zero combustion emissions.

Resistance Electric Steam Boiler — YXBOILER (YONGXING BOILER) Manufacturer & Factory

YXBOILER (YONGXING BOILER) is a leading electric steam boiler manufacturer and factory based in Taikang, Henan Province, China — widely recognized as the "Boiler Capital of China." With over 40 years of manufacturing experience, YXBOILER has established itself as one of China's most trusted industrial thermal equipment suppliers, successfully exporting premium products to over 80 countries and regions worldwide. Our resistance electric steam boiler is precision-engineered to meet demanding international quality standards, combining cutting-edge technology, rugged construction, and highly competitive factory-direct pricing.

As a fully integrated manufacturer, YXBOILER controls every step of the production process — from raw material sourcing and component fabrication to final assembly, testing, and packaging. This vertical integration allows YXBOILER (YONGXING BOILER) to guarantee superior product quality while offering prices significantly lower than comparable products from trading companies. When you purchase directly from the YXBOILER factory, you receive genuine manufacturer pricing with full factory warranty and after-sales support.

☑ Working Principle & Technology

The Resistance Electric Steam Boiler by YXBOILER converts electrical energy directly into steam through high-grade stainless steel immersion heating elements, achieving near 100% thermal efficiency with zero combustion emissions.

The resistance electric steam boiler manufactured by YXBOILER (YONGXING BOILER) incorporates decades of engineering expertise and the latest technological innovations. Every unit undergoes a meticulous 7-step quality inspection process that ensures compliance with China's A-Class boiler manufacturing standards and international certifications including ASME, CE, ISO 9001, and ISO 14001. This rigorous quality assurance program has earned YXBOILER the trust of more than 12,000 customers worldwide across diverse industries and applications.

☑ Technical Specifications

ModelYX-LDR-0.05YX-LDR-0.1YX-LDR-0.3YX-LDR-0.5YX-LDR-1.0YX-LDR-2.0
Capacity0.05 t/h0.1 t/h0.3 t/h0.5 t/h1.0 t/h2.0 t/h
Pressure0.7 MPa
Steam Temp171°C
Power36 KW72 KW216 KW360 KW720 KW1440 KW
Efficiency≥99%

☑ Key Features & Advantages

  • ☑ Zero Emissions: No combustion, zero flue gas, zero CO2/NOx/SOx
  • ☑ ~100% Efficiency: Direct electrical-to-thermal conversion
  • ☑ PID Control: Temperature within ±1°C
  • ☑ Compact Design: No chimney or fuel storage needed
  • ☑ Fully Automatic: PLC with auto water level and pressure control
  • ☑ Multi-Protection: Over-temp, over-pressure, water shortage, phase-loss

☑ Applications & Industries

The YXBOILER Resistance Electric Steam Boiler serves food processing, pharmaceutical manufacturing, textile production, laboratory research, hospital sterilization, concrete curing, and chemical processing.

☑ Quality Assurance & 7-Step Inspection

  1. Material Inspection: All raw materials inspected upon arrival at the YXBOILER factory with traceable identification.
  2. Welding Procedure Qualification: Test welds ensure highest quality before production.
  3. Post-Weld Heat Treatment: Critical welded joints undergo heat treatment to reduce stress.
  4. Pre-Expansion & Fit-Up: Precision pre-expansion before formal welding.
  5. 100% NDT Testing: Radiographic, ultrasonic, magnetic particle, and liquid penetrant testing.
  6. Hydrostatic Test: All pressure parts tested at 2× design pressure for minimum 25 minutes.
  7. Final Inspection: Complete inspection covering dimensions, performance, safety devices, and documentation.

☑ Why Choose YXBOILER (YONGXING BOILER)?

CriteriaYXBOILER (YONGXING BOILER)Typical Competitors
CertificationsA-Class Boiler, ISO 9001, ISO 14001, ASME, CEBasic or no certifications
Quality Control100% NDT testing, 7-step inspectionSample testing only
Factory Scale66,000 m², 336 equipment setsSmall workshop
Export Experience80+ countries, 12,000+ customersLimited export history
Warranty12-60 months, lifetime support6-12 months standard

☑ After-Sales Service Commitment

  • 5% Spare Parts Included with every shipment from YXBOILER factory
  • Factory-Direct Wearing Parts Pricing for all replacement components
  • A-Class Installation Team available for on-site commissioning worldwide
  • Free Warranty Repairs during the warranty period
  • Preventive Maintenance every 6 months through local service teams
  • 24/7 Technical Hotline for emergency support

☑ Related Products from YXBOILER

☑ About YXBOILER (YONGXING BOILER) Group

Henan Yongxing Special Equipment Co., Ltd. — operating globally as YXBOILER — is one of China's largest industrial boiler manufacturers. Our facility in Taikang Industrial Zone covers 66,000 square meters with over 1,000 skilled workers and engineers. The YXBOILER group includes Taikang ZhongXin Boiler Co., Ltd. and Jinma Boiler Equipment Co., Ltd.

☑ FAQ

What certifications does YXBOILER hold?

YXBOILER holds A-Class Boiler Manufacturing License, ISO 9001:2015, ISO 14001:2015, ASME, CE, and multiple international certifications.

What is the warranty period?

12 months from commissioning or 18 months from delivery. Extended warranty up to 60 months available.

Can YXBOILER customize this product?

Yes. YXBOILER offers full ODM/OEM customization tailored to your requirements.

Manufacturing and delivery time?

Standard models: 15-25 working days. Custom models: 25-45 working days.
